Acrylic glass red fluorescent laser-cut

Configure your individual laser parts made of acrylic glass in fluorescent red online and benefit from the flexible, diverse configuration options. Available in 3mm thickness up to 1500mm length and 980mm width. The sheets are red transparent and have a reduced light transmission of approx. 12% due to the colouring. The edges have a fluorescent, self-luminous effect.

Delivery Time: Dispatch within 7 working days

+ Basic form Choose one of the available basic shapes.
All necessary input fields will be loaded based on your selection.

  • Rechteck als Laserform
  • Abgerundetes Rechteck als Laserform
  • Kreis als Laserform
  • Kreisring als Laserform
  • Ellipse als Laserform
  • Halbkreis als Laserform
  • Viertelkreis als Laserform
  • Octagon als Laserform
  • Trapez als Laserform
  • Dreieck als Laserform
  • Rechtwinkliges Dreieck als Laserform
  • Route als Laserform
  • Stern als Laserform
  • Polygon als Laserform
Your price €0.00 Incl. % Tax Weight: 0,0000 kg

+ Drilling-hole Select size, spacing, and positions for optional drilling-holes.
Depending on the chosen basic form, there are different variants available.

  • No drilling-holes will be made
  • Drilling-holes centered on laser part
  • Drilling-holes centered on each side
  • Drilling-holes in every corner
  • Drilling-holes above and below
  • Drilling-holes left and right
  • Lochbohrungen an jeder Seite

without drilling-holes

No drilling-holes are placed on the laser part.

Your price €0.00 Incl. % Tax Weight: 0,0000 kg
Description

Acrylic glass red fluorescent laser cut

Our acrylic sheets in red with fluorescent edge are available in laser cut up to a maximum format of 1500mmx980mm. The sheets are red transparent and have a light transmission of approx. 12% due to the strong red colouring. The special feature of the fluorescent sheets is the luminescent effect on the cut edges, which is particularly effective during laser cutting. In order to guarantee you laser cuts in perfect quality, we only use cast acrylic sheets for our bright red acrylic glass. The special manufacturing process allows us to achieve a polished, smooth cut edge that almost resembles the surface of the sheets. This has a very clear effect on the luminous effect, especially with the fluorescent sheets.

The red acrylic sheets are completely coloured through and have a high and consistent pigmentation. They are solid sheets and not twin-wall sheets or double-wall sheets.

NOTE: Our fluorescent acrylic sheets in red are equipped with a protective film on both sides to protect the surfaces. However, this can be easily removed after processing is complete.

Properties of the acrylic glass in red fluorescent

Fluorescent acrylic sheets are available in our online shop in various colours as laser cuts. The special feature of these special sheets is that the cut edges have an effect comparable to shining a light source on them. This luminous effect is made possible by the addition of special colour pigments and comes into its own best at dusk and in indirect light. Especially as a wind chime in the garden, as a brochure stand or as a whiteboard combined with special board markers, the bright red acrylic glass panels make for a special eye-catcher. These sheets can also be used in the field of advertising technology. For example, for coloured light installations or for eye-catching product presentations.

The surfaces of the acrylic sheets are transparent and smooth and have a reduced light transmission of about 12%. The reduced light transmission is due to the high pigmentation in the colour red, which is necessary for a strong, rich colouring of the plastic sheet.

Acrylic glass is the simpler name for polymethyl methacrylate (PMMA for short) and is better known to most people under the brand name Plexiglas® instead of the plastic name. Acrylic glass is a UV-resistant plastic that is equally suitable for indoor and outdoor use. The resistance to UV radiation contributes, among other things, to the fact that the laser parts do not become brittle. Another advantage of the UV resistance is that the bright red colour pigments do not fade even with permanent outdoor use. The red acrylic sheets are waterproof and weather-resistant and can withstand winter temperatures of up to -40°C. But even at high temperatures of +80°C, the laser blanks made of fluorescent PMMA can be used permanently.

This makes the colourful acrylic sheets with a luminous effect perfect for radiant decorations in the garden, on the balcony or on windows.

  • Acrylic glass red fluorescent is weatherproof and UV-resistant and suitable for outdoor applications
  • Acrylic glass red fluorescent has a high surface hardness and is relatively insensitive to scratches
  • Acrylic glass red fluorescent has an impact strength 8 to 10 times higher than glass
  • Acrylic glass red fluorescent can be used at temperatures from -40°C to +80°C
  • Acrylic glass red fluorescent has a reduced light transmission of approx. 12%
  • Acrylic glass red fluorescent impresses with a rich red colour with radiant edges
  • Acrylic glass red fluorescent is classified as normally combustible (according to DIN 4102 B2, UL94 HB)

Advantages of acrylic glass red fluorescent in laser cutting

Configure your laser cuts in no time at all with our simple laser part configurator. With 14 basic shapes and many other configuration options, you can very quickly create your individual laser cuts made of acrylic glass in fluorescent red. Thanks to true-to-scale real-time preview, you always get an exact overview of the effects of your entries. As soon as you have finished configuring your laser cuts and the order is completed, the data is converted into a format that can be read by our laser and automatically transferred to the corresponding laser system. Thanks to the optimised processes, we are not only fast, but also extremely cost-effective.

With our laser service, however, you not only benefit from the easy-to-use configurator. Especially with transparent plastics such as acrylic glass, laser cutting has a positive effect on the cut edge, which does not appear rough and cloudy but smooth and polished. Especially with fluorescent acrylic glass sheets, the luminous effect is particularly effective. This is also the reason why we offer these plastic sheets exclusively in laser cut.

  • Fluorescent acrylic laser parts have a smooth, even cut edge with a luminous effect
  • Laser parts can be produced with a very high dimensional accuracy thanks to non-contact cutting
  • Laser cutting of red acrylic glass means that the blanks do not have sharp edges or burrs
  • Laser cutting offers maximum flexibility for individual shapes, for example as garden decoration
  • With our configurator, laser cuts of red acrylic glass are possible in many shapes

NOTE: The maximum size of our acrylic laser parts is limited to 1500mmx980mm.

Post-processing of laser cuts from acrylic glass

Cutting and drilling acrylic glass with woodworking tools is possible without further ado. However, this is associated with a reduction in the luminous effect of the transparent sheets with fluorescence, which is why we do not recommend machining methods. If you still want to saw the sheets, you can use conventional hand-held circular saws or jigsaws for cutting. A medium-density toothing of the saw blade leads to the best results. However, acrylic glass can break, so the sheet should rest firmly on a flat surface and be fixed in place. Thanks to our laser cuts, which we perform for you with very high precision according to your configuration, cutting the acrylic sheets to size should not be necessary, however.

The bright red acrylic glass can be glued to make colourful decorative objects from different coloured laser parts, for example. It must be said that laser parts made of extruded acrylic glass release stresses, which can lead to stress cracks, especially with solvent-based adhesives. However, since we only use cast acrylic sheets for our laser cuts, where no stresses occur within the sheet due to the special manufacturing process, no stress cracks occur when bonding with solvent adhesives. If you want to glue your laser blanks, we recommend our acrylic glass adhesive PMMAprofi.

Acrylic glass can be deep-drawn and due to the fluorescent effect, an exciting, thrilling effect can be achieved by thermoforming, especially with the red acrylic glass sheets. For thermoforming, a temperature range between 150°C and 190°C should be selected. Please note that the protective films are not thermoformable and must therefore be removed beforehand.

  • Fluorescent Acrylic Red can be drilled, routed or sawn without any problems
  • Red fluorescent acrylic can be bonded with solvent-free adhesives
  • Fluorescent Acrylic Red can be thermoformed at temperatures between 150°C and 190°C
  • Red fluorescent acrylic can be screwed, e.g. with stainless steel wall brackets

WARNING: Laser cuts made of acrylic glass must not be cleaned with alcohol. This can lead to stress cracks on the laser edges.

More complex shapes and laser engravings on request

With our laser systems, we are able to create laser cuts according to your design drawing in almost any shape. We can also create individual letters, lettering or laser engravings for you from our fluorescent acrylic sheets with a luminous effect. However, this is not yet possible with our configurator and is currently only available on request. Our friendly team will be happy to inform you about prices and possible delivery dates. Simply give us a call or send us an e-mail with the necessary details and we will provide you with information as quickly as possible.

    Further possibilities of our CO2 laser system on request:

  1. Letters and lettering in laser-cut acrylic glass red fluorescent
  2. Laser cuttings in any shape according to your drawing in vector format
  3. Individual perforated plates and any cut-outs in acrylic glass red fluorescent
  4. Laser engravings with luminous effect made of acrylic glass red fluorescent
  5. Series production of laser cuttings from acrylic glass red fluorescent
  6. and much more

Plexiglas® is a registered brand name of Röhm GmbH.

Additional Information

Additional Information

Product-ID51940L
WeightN/A
Thickness3mm
Standart Length1520
Standard width1010
Delivery TimeDispatch within 7 working days
PlasticAcrylglas
MaterialPMMA
UV resistanceUV resistant
ColorRed
Color accuracyColor similar to RAL color system
RAL color codeRAL3024
Color designationRed fluorescent
