Acrylic glass transparent laser-cut

Configure your individual laser parts made of transparent acrylic glass (PMMA, also known under the brand name Plexiglas®) in thicknesses from 2mm to 10mm inexpensively online and benefit from the flexible, diverse configuration options.

Delivery Time: Dispatch within 7 working days

Formen

+ Basic form Choose one of the available basic shapes.
All necessary input fields will be loaded based on your selection.

  • Rechteck als Laserform
  • Abgerundetes Rechteck als Laserform
  • Kreis als Laserform
  • Kreisring als Laserform
  • Ellipse als Laserform
  • Halbkreis als Laserform
  • Viertelkreis als Laserform
  • Octagon als Laserform
  • Trapez als Laserform
  • Dreieck als Laserform
  • Rechtwinkliges Dreieck als Laserform
  • Route als Laserform
  • Stern als Laserform
  • Polygon als Laserform
Your price €0.00 Incl. % Tax Weight: 0,0000 kg

+ Drilling-hole Select size, spacing, and positions for optional drilling-holes.
Depending on the chosen basic form, there are different variants available.

  • No drilling-holes will be made
  • Drilling-holes centered on laser part
  • Drilling-holes centered on each side
  • Drilling-holes in every corner
  • Drilling-holes above and below
  • Drilling-holes left and right
  • Lochbohrungen an jeder Seite

without drilling-holes

No drilling-holes are placed on the laser part.

Your price €0.00 Incl. % Tax Weight: 0,0000 kg
Description

Individual laser parts made of transparent acrylic glass

With our laser parts made of acrylic glass in transparent design, we offer you the possibility to conveniently order acrylic glass sheets online in almost any shape. Our laser cuts are made of solid acrylic glass and can be laser cut in different thicknesses from 2.0mm to 10.0mm up to a maximum format of 1500mmx980mm. Our acrylic sheets are always high-quality solid-core sheets and not hollow-core or double-skin sheets. They are manufactured in Germany and comply with the REACH and RoHS declaration of conformity.

NOTE: Our acrylic sheets are equipped with an easily removable protective film on both sides to protect the surfaces from scratching before and during processing.

What is transparent acrylic

Acrylic glass (better known to most under the brand name Plexiglas®) is a UV-resistant, weatherproof plastic that is equally suitable for indoor and outdoor use. Thanks to the high surface hardness, our transparent acrylic glass, in contrast to the also transparent polycarbonate, is characterised by a relatively scratch-resistant surface, but due to the brittleness of the plastic, it is sensitive in terms of breaking behaviour, so that acrylic glass can break in the event of impacts or blows.

  • Transparent acrylic glass is weatherproof and UV-resistant and therefore easily suitable for outdoor applications
  • Transparent acrylic glass has a high surface hardness and is therefore comparatively scratch-resistant
  • Transparent acrylic glass can be used permanently at temperatures from -40°C to +80°C
  • Transparent acrylic glass has a very high light transmission, which even exceeds that of real glass

Advantages of our laser cuts made of transparent acrylic glass

In contrast to conventional cuts on our panel saws, the cut edges of the laser parts do not have a saw-rough surface. By cutting with our powerful CO2 laser systems, the laser edges are evenly smooth. This is a great advantage, especially when laser cutting transparent acrylic glass, because the surfaces of the cut edges are clear and transparent. This also has an effect on the high-quality appearance, especially of company signs or transparent shelves and doors of showcases and cabinets.

The biggest advantage compared to cutting on our panel saws, however, is that you are not limited to rectangular formats, but basically any shape can be laser-cut from our acrylic glass panels. Even complex cut-outs in all imaginable shapes, including letters, are possible without further ado.

  • Laser parts made of transparent acrylic glass have a smooth, transparent cut edge
  • Laser parts made of transparent acrylic glass are cut with an extremely low manufacturing tolerance
  • Laser cut parts are made from solid acrylic, in a choice of 2mm, 3mm, 4mm, 5mm, 8mm or 10mm
  • Lasered acrylic is ideal for transparent company signs or door signs, even with laser engraving on request
  • Lasering does not affect the application possibilities and the weatherproof properties of acrylic glass

Advantages of our laser part configurator

With our laser configurator, individual shapes can be created within a very short time with just a few entries. For this purpose, 14 basic shapes are available, each with corresponding input fields to adapt the basic shape to your specific needs. From simple rectangles, rectangles with rounded corners, circles, circular rings, ellipses or triangles, to polygons with any number of corners, hardly any wish remains unfulfilled. Even the placement of holes can be done with a few clicks, depending on the selected basic shape.

Your entries are displayed in real time in a small preview so that you can see your laser shape immediately after entering it and change it if necessary. The price calculation of your acrylic laser parts also takes place as soon as all the necessary input fields have been filled in and adapts to your entries at any time.

Once you are satisfied with your configuration and have added your custom acrylic laser part to the shopping cart and completed the ordering process, a file is generated in the background that is automatically sent to one of our laser facilities, ensuring smooth and fast delivery of your lasered acrylic sheets.

  • Laser parts made of acrylic sheets can be created in just a few steps using our configurator
  • There are 14 basic shapes and a variety of configuration options available for your laser parts
  • You can add holes to your acrylic laser shape with just a few clicks
  • You can check your input in the real-time preview and easily adjust it if necessary
  • Instant price calculation responds to every input and takes quantity discounts into account automatically
  • The finished files are automatically generated and processed in a laser-readable format

NOTE: The maximum size of our laser parts made of transparent acrylic glass is limited to 1500mm x 980mm due to the design of our CO2 laser systems. Larger formats can only be produced by conventional rectangular cutting on our CNC panel saws.

Post-processing of laser parts made of transparent acrylic glass

Similar to conventional cuts from our transparent acrylic glass sheets, our laser cuts can also be processed further without any problems. All cutting methods such as sawing, milling or grinding are available for this purpose. Drilling acrylic glass is also possible. However, it should be noted that the acrylic glass sheet should lie flat so that it does not flutter during sawing or drilling, which can result in chipping or cracking.

Lettering with a film or digital print is also possible with transparent acrylic glass. For a particularly visually appealing effect, the lettering can be applied to the back of the lasered acrylic glass panel. However, it should be noted that the inscription must be applied mirror-inverted.

  • Laser parts made of transparent acrylic glass can be easily cut to size or drilled
  • Laser parts made of transparent acrylic glass can be covered with foil or digital prints
  • In particular with laser engravings, cutting lighting effects can be created
  • Laser parts made of acrylic glass can be screwed or glued together (do not use solvents)

WARNING: Laser parts made of transparent acrylic glass must not be cleaned with alcohol or bonded with solvent-based adhesives (e.g.: our S-Polybond PMMAprofi), as this can cause stress cracks to form at the laser edges.

More complex shapes and laser engravings on request

With our laser part configurator, the most common shapes for configuring your individual laser parts made of acrylic glass in transparent are available and the placement of hole drillings is also possible via our input fields, but more complex shapes, individually placed hole drillings or even cut-outs in certain shapes cannot be easily generated online.

If you require more specific requirements in terms of shaping, positioning, size and number of perforation holes, right up to perforated plates made of transparent acrylic glass, we will be happy to assist you at any time.

    Further possibilities of our CO2 laser system on request:

  1. Individual laser cuts from transparent acrylic glass up to 10mm thick according to your drawing
  2. Individual perforated plates or any cut-outs from lasered acrylic glass in transparent
  3. Laser engravings as lettering or lasered graphics (logos, symbols, black & white graphics & photos)
  4. Reproducible series production of laser parts made of transparent acrylic glass
  5. and much more

For the calculation of your individual laser parts made of transparent acrylic glass, simply send us your enquiry with a sketch or design drawing stating the desired thickness and delivery quantity and we will send you an offer according to your requirements as quickly as possible. Please note that we always require a digital vector drawing (EPS, AI, SVG, DXF, DWG) for laser cutting.

Plexiglas® is a registered brand name of Röhm GmbH.

Additional Information

Additional Information

Product-ID50000L
WeightN/A
Thickness2mm - 10mm
Standart Length3050
Standard width2050
Delivery TimeDispatch within 7 working days
PlasticAcrylglas
MaterialPMMA
UV resistanceUV resistant
ColorColorless
Color accuracyNo
RAL color codeN/A
Color designationTransparent
